EKM PRO
Compatible with R134a or R1234yf
After completely emptying the gas from the tank, the new generation EKM PRO can be used with R134a or R1234yf refrigerants.
Compatible with R134a or R1234yf
After completely emptying the gas from the tank, the new generation EKM PRO can be used with R134a or R1234yf refrigerants.
Android Operating System
Crafted with a beautiful design and advanced technology, the EKM PRO is a truly unique 7-inch Android tablet offering incredible ease of use.
With EKM PRO, which allows the operator to remotely control and monitor the device via Bluetooth connection, you can perform all data updates free of charge over the internet via Wi-Fi connection.
Thermal Printer
A high-speed, thermal printer with 57 mm paper capacity is offered as a standard feature.
Remote Connection
In the event of a malfunction, an Elci technician can remotely connect to your tablet to quickly diagnose and fix your problems.
Simple, Accurate and Efficient
EKM PLUS 2 uses an electronic scale for accurate and continuous monitoring of refrigerant gas. This highly efficient gas recovery device also performs automatic leak detection with the help of a highly sensitive vacuum sensor.
Device Features
● Gas extraction, air release, oil draining, vacuuming, leak testing, oil injection, and gas filling processes are performed automatically without requiring user intervention.
● 8GB memory, 1.2 GHz processor
● 7-inch touchscreen, 1024 × 600 resolution
● Easy-to-use control panel
● High-efficiency gas recovery (compliant with A-R-I standards)
● Automatic leak detection system via high-precision vacuum sensor.
● ABS body
● High pressure protection system
● High-precision temperature sensor
● Automatic tank full warning and shut-off.
● Automatic oil drain
● Automatic oil injection
● Otomatik UV sıvı enjeksiyonu
● Automatic air release
● Gas purifier filter to separate acid, moisture and particles from the refrigerant gas.
● Bluetooth connection allows you to wirelessly control the machine remotely with any phone or tablet.
● Wireless bağlantısı ile internetten yapılan güncellemeleri ücretsiz indirme
● Thermal printer for 57 mm paper
● Filter, vacuum pump oil and compressor oil maintenance reminders
● Heating belt to speed up the gas filling process while maintaining a constant temperature.
● Four swivel wheels, two front wheels for excellent maneuverability.
Technical Specifications
Compressor
3/8 HP 12 cc hermetik
Dimensions
55 cm x 58 cm x 113 cm
Screen
7 inch touch
Filter Capacity
150 kg
Hose Length
300 cm
Operating Temperature
8° – 49° C
Power
220 V ± 10% / 50 Hz
Gas Drawing Rate
450 gr/dak
Gas Type
R134a & R1234yf
Scale Sensitivity
± 5 gr gaz, ± 1 gr oil
Gas Storage Tank
15 kg
Vacuum Pump
7.68 m³/h (2 stages)
Weight
84 kg
Optional Features
Gas Tank
25 kg
Vacuum Pump
10.2 m³/h
Gas Purity Test
Air Conditioner Washing Kit for R1234 yf
